Tail
Gate Lifts
Lift
Capacities regarding vehicle type;
Strong and durable Aluminum platform
for Mini Van, Van, Light/Medium/Heavy
Truck models,
- 500 / 1000 /
1500/ 2000/ 2500 kg
- Hydraulic unit: 24 / 12 V
- Lifting Speed: 60-80 mm/sec.
- Hydraulic Oil : #68
- Tilt Angle: 5-9 degrees
- Specially designed D.C. hydraulic unit,
- Engine Power: 2.5 KW 24V, 200A
- Lifting capacity :1000/1500/2000 Kg
- Height
/ Arm Length : 1150/700 mm /
1450/900 mm
- Platform Material: Aluminum
- Platform
Dimension: 2200 x 1800 mm / 2500 x
1800 mm
- Sealing in European standards with single acting cylinder,
- Special self-lubricating bronze bearing,
- Possibility of speed adjustment in lowering and downward inclination,
- Fasteners with special coating against rust,
- Manual control of valves in emergency situations,
- Thermal current cut-off in case of overheating thanks to electric-motor automatic protection system,
- Pressure regulated valves,
- Metal control panel,
- Smooth control system operating ,
- Automatic inclination system when the platform descends and rises,
- Reflective warning flags and plaques,
- High strength sub-assembly structure,
- Easy maintenance and practical use,
- Safety switch for emergencies,
- Fixed
control from the power unit with
joystick, hand control system with
spiral cable,
- CE compliant, 3-piece profile bumper,
- Safety valve system against hose burst,
- Suitable for all truck models and easy installation,
